Products
Inline Ultrasonic Food Slicing Machine
The ultrasonic sliding machine's cutting blade is continus moving with conveyor belt synchronously . Increse the cutting speed with continus moving and two combine blades . The machine designed to meet high hygiene standards, food-safe materials and stainless steel are used.The machine could be connect with bakery production line and packing machine line .It's good choice to used for candy bar ,chocolate,cereal bar,marshmallow etc foods cutting.It's ideal for medium output operations which demand a configurable and easy-to-use machine.
FEATURES
- Ultrasonic vibration reduces friction resistance between the blade and food, and it
makes the blade cut smoothly without deformation.
- The cutting blade is made of titanium. It is completely inert and enduring material.
- Because it reduce the chips of food during cutting and foulings on the blade, you can
reduce the down time to cleaning and increase the productivity.
- It is suitable for the food products which include different hardness foods
- Japan Panasonic servo-motor driving , it's more stable and precision
SPECIFICATIONS
Model | BDS-FA200 |
Voltage | 220-240V,50/60Hz |
Frequency | 20KHz |
Ultrasonic Unit | 2 Groups |
Cutting Height | Below 60mm |
Cutting Width | 600mm |
Dimensions | L2000mm x W950mm x H1800mm |
Weight | About 600 KG |
APPLICATIONS
Cheeses slicing: wheel, block, cheddar, feta, mozzarella, parsley block, cheese log, …
Cooked meat cutting: pate, ham, parsley ham, foie gras, quiche, pie, …
Pastries portioning: pie, dessert, cake, gingerbread, cookie, puff pastry, …
Confectioneries slicing: nougat, fruit paste, caramel, almond paste, fruit candy, cereal bars, chocolate, marshmallow, ganache, brittle, …
Servings and delis: wraps, sushis, sandwiches, …
Frozen foods: all kinds
